Quality Assurance, Service Priority.
2 Years
| Ask Lasest Price | |
| Brand Name : | Delta |
| Model Number : | ZKD |
| Certification : | ISO9001 |
| Price : | USD1.0 |
| Payment Terms : | T/T, Western Union |
| Supply Ability : | 1000 sets per month |
| Delivery Time : | 10 days |
Parameters:
1 | Detection objects | various models of vacuum switch |
2 | Detection method | using new excitation coil and detect vacuum tube without disassembly |
3 | Application area | This instrument is a all-purpose type, can measure the vacuum of variety models of open magnetic vacuum tube |
4 | Detection range | 10 -5 -10 -1 Pa |
5 | Measurement accuracy | 10 -5 -10 -4 Pa, 10% 10 -4 -10 -3 Pa, 10% 10 -3 -10 -2 Pa, 10% 10 -2 -10 -1 Pa, 10% |
6 | Magnetic field voltage | 1700V |
7 | High-voltage of pulsed electric field | 30KV |
8 | Open distance of switch tube in vacuum test | normal open distance |
9 | Testing environment | -20℃~ 40℃ |
10 | Weight | 12kg |
11 | Dimension | 420 × 320 × 280 (mm) |
12 | Sampler | magnetic coil |
|
|
